AFFORDABLE HYDRAULIC HOME LIFT
Hydraulic home lift is a hydraulic platform lift with frame installed in small spaces. It is composed of hydraulic system, lifting platform and outer frame. Different from general traction motor elevators, household small home elevators are more suitable for small loads and small installation space. We will design the overall size according to the installation space inside the customer’s home. This equipment is cheap, easy to operate, low maintenance costs, very suitable for 2-4 storey building installation. It also has the advantage of beautiful appearance. Various colors of the outer frame for customers to choose. Customers can choose the material color of the equipment according to their home interior decoration. Its use environment includes home, hotel, hospital, shops, office building and so on.
- System: Hydraulic
- Inside Lift Material: Aluminum Alloy
- Outside Frame Material: Aluminum Alloy and Tempered Glass
- Motor type: Silent Hydraulic Pump Station
- Doors: Electric open or Automatic open
- Controllers: Digital COP and LOP, Remote controller
- Colors: 8 Standard Colors for Choice
- Install space: Small Spaces Available
- Safety Measurement: Anti-drop, Safety Board, Emergency locks, Emergency down
- Optional choices: UPS, Automatic doors, Flooring materials etc.
- Accept customization for heights and cabin sizes
- Prices: from USD8,000~USD20,000. Depending on heights and specs.
Affordable Hydraulic Home Lift Models
|
Model
|
Lifting Height
|
Capacity
|
Clean Platform Size
|
Lift Type
|
Voltage
|
|---|---|---|---|---|---|
|
HVLW-2
|
2.0m
|
300kg
|
1000*1430mm
|
Lift with Frame
|
110V/220V, Single Phase
|
|
HVLW-3
|
3.0m
|
300kg
|
1000*1430mm
|
Lift with Frame
|
110V/220V, Single Phase
|
|
HVLW-6
|
6.0m
|
300kg
|
1000*1430mm
|
Lift with Frame
|
110V/220V, Single Phase
|
|
HVLW-9
|
9m
|
300kg
|
1000*1430mm
|
Lift with Frame
|
110V/220V, Single Phase
|
|
Other heights, capacity, lift size can be customized as per your request.
|
|||||
Affordable Small Hydraulic Home Lift Testing Videos
What We Do to Produce Qualified Hydrualic Home Lift
Electric cabinet with PLC
Silent Pump Station
Electric Door & Automatic Door for choices
LOP On each stop
COP inside
Remote Control
Safety Board Under Platform
Safety Limit Switches
Doors With Safety Interlocks
250mm Width Lead Rail
Aluminum Alloy Frame
Easy but Strong Assemble
FAQS
There are few factors influence the small hydraulic home lift cost. Lifting height, landing door types, cabin inside or not, UPS and other optional configurations. Each factor will affect the lift price. So the small hydraulic home elevator prices are around us dollars 5000 to 20000. Welcome to contact our sales team.
The standard speed for hydraulic system is 4m/minute. Himor’s hydraulic home elevator speed is 6m/minute.
When you press the LOP, the platform will come to you, and the doors open by itself. After you go into the lift, the door will close itself. It is very convenient for people to use.
The max. Travel height can be 15 meter. Normally clients ask for 2-4 floors which is around 3m to 9m.
Yes. We use aluminum alloy material which is not easy to rust as its main material. As long as the outdoor installation conditions allow, then it can be used outdoors.
Firstly, in our standard configuration, you can lower down the platform by manual valve on ground. Secondly, if you add 1kva UPS for battery power backup, you can lower down the lift directly when electricity power goes out. Thirdly, if you add 10kva UPS for backup, you can both lift up or lower down the lift directly when electricity power goes out.
The ground of the site should be concreted, which depth should be more than 200mm. The lift must near to the wall or the floors, and there is concreted or steel structure to fix the upper parts of the lift.
- The lifting system difference. Hydraulic lift’s lifting mechanism is cylinder and chains.
- Prices difference. Hydraulic elevator is pretty cheaper than traction lifts.
- Sizes difference. Normally hydraulic lifts are smaller, and more suitable for narrow places installation.
- Capacities difference. Standard capacity of hydraulic lift platform is 300kg, and max. 500kg.
- Machine room difference. Hydraulic lift does not need machine room.
- Pit difference: our lifts platform pit can be 100mm-150mm. If the site is not suitable to make a pit, we can make a small ramp for easier access.
